52V 25Ah Down Tube Battery
70 LG 21700 cells behind a 50A BMS, in a lockable hard case that bolts to your bottle bosses.
52VNominal
25AhCapacity
1300WhEnergy
50ABMS
  • Fits frames a triangle pack won’tBolts to the down tube rather than filling the frame triangle. If your triangle is small, oddly shaped or already occupied, this is the pack that goes on.
  • 70 genuine LG 21700 cells14 in series, 5 in parallel, 5000mAh each. Not a mystery cell in a nice case.
  • Comes off with the keyUnlock it, lift it off the rail, charge it indoors and leave the bike in the shed. Two keys supplied.
Buying a full kit? We fit it free Any complete conversion kit bought from us is fitted free of charge at our workshop. Bring the bike in and ride it away. Kits bought elsewhere are £100. 34 Brindley Road, Manchester, M16 9HQ · Open 08:00–18:00 Ring 0161 706 1851 to book a slot, or bring the bike down and we will check this pack against your frame before you commit. Get directions34 Brindley Road, Manchester M16 9HQ ›

You need a clear straight run of at least 368 mm on the down tube and a pair of bottle bosses — open “Will it fit your frame” below before you order.

What’s included
  • 52V 25Ah down tube battery — 70 LG 21700 cells, 50A BMS
  • Mounting rack — plate, bolts and XT60 lead
  • 2 x keys
  • 58.8V charger — UK plug
What motor does this suit?

Straight answer, and here is the arithmetic behind it so you can check it yourself.

50A BMSAt 52V that is a ceiling of about 2,600W. The battery management is what physically limits the current, so that is the real number.
On a 2000W motorA 2000W motor pulls roughly 38A at full throttle. That leaves about 30% in reserve, so the pack is not working at its limit every time you pull away or climb.
Not a 3000W packA 3000W motor would draw around 58A, which is past the 50A BMS. If you are running 3000W, this is the wrong battery — talk to us first.
Will it fit your frame?
1Measure your down tube. This bolts to the bottle bosses, so you need a clear straight run of at least 368 mm with nothing in the way. The rail has four slots at 61 mm centres, so it adjusts to most standard boss positions.
368.3 mm long 141 mm 61 mm 61 mm 89.8 mm deep · mounting rack adds about 9 mm
2Check the clearance. Allow for the pack standing about 90 mm off the tube once the rack is on. Watch for a front derailleur cable, a bottle cage, or a shock on full suspension frames.
3Check your controller. The 50A BMS is the ceiling. Suits systems up to 2000W at 52V — check what your controller actually draws rather than going by motor wattage alone.
?Still not sure? WhatsApp +44 7493 275057 with a photo of your down tube, or bring the bike to the workshop between 08:00 and 18:00 and we will offer the pack up against it.
Full specification
Nominal voltage 52V
Capacity 25Ah
Energy 1300Wh
Cells 70 x LG 21700 5000mAh (14S5P)
Battery management 50A BMS
Power ceiling at 52V About 2600W
Suits motors up to 2000W
Operating voltage 42V to 58.8V
Charge cut-off 58.8V
Charge time 8 to 9 hours
Mounting Down tube, bottle bosses
Dimensions 368.3 x 141 x 89.8 mm
Rack bolt spacing 61 mm centres, 4 slots
Connector XT60 on 5 pin rail
Security Lockable, 2 keys
Which 52V pack should I pick?

Four to choose from. The differences are capacity, where it mounts, and how much power it will pass.

20Ah down tube — 1040Wh, 5.5 kgLightest and cheapest. Rated 1500W to 2000W, so it suits a 2000W kit ridden normally rather than flat out.
25Ah down tube — this one, 1300Wh50A BMS, a 2600W ceiling. More capacity than the 20Ah and more headroom on a 2000W motor. Same down tube mount.
25Ah triangle — 1300Wh, 8.2 kgSame capacity in the frame triangle, rated 1500W to 3000W with 1000 cycles. Charges faster at 5 to 6 hours. Needs a 16 inch frame.
30Ah triangle — 1560Wh, 8.5 kgMost range. Needs an 18 inch frame. Available as the HS-II, or our own Smart pack with Samsung cells and Bluetooth.
Charging and looking after it
ChargingUse the charger supplied. Charge on a hard non-flammable surface, never unattended and never overnight. A full charge from empty takes eight to nine hours, so plan it rather than leaving it on.
StorageIf the bike is going away for a few weeks, leave the pack around half charged rather than full or flat, somewhere dry and cool.
Stop using it ifthe case is swollen, cracked or dented, the pack gets hot, or it behaves oddly. Move it somewhere safe away from anything that can burn and ring us.
Questions we get asked
What motor will this run?Up to 2000W at 52V. The 50A BMS gives a ceiling of about 2600W, and a 2000W motor draws around 38A, so there is roughly 30% in reserve. It is not suitable for 3000W systems.
Will it fit my down tube?You need a clear straight run of at least 368 mm and a pair of bottle bosses. The rack slots adjust across 61 mm centres, which covers most standard frames.
Can I take it off to charge?Yes. It unlocks from the rack with the key and lifts off, so you can charge it indoors and leave the bike outside or in the shed.
Why does this take longer to charge than the triangle pack?It ships with a smaller charger, so a full charge from empty is eight to nine hours rather than five to six. Ring us about a faster charger if that matters to you.
Can I post it back if it does not fit?Not through the post. Lithium packs this size are restricted goods and travel by road courier only. Ring 0161 706 1851 and we will arrange collection.
What if something fails?Ring 0161 706 1851 or WhatsApp +44 7493 275057. Twelve months on manufacturing defects, and because we are a workshop rather than a warehouse we can usually diagnose a fault from a photo instead of making you send it back.
Dispatch, returns and warranty
DispatchSame working day on orders placed before 9am, otherwise the next working day. Batteries travel by road courier only.
Returns30 day money back. Battery must be unused and in its original packaging. Ring 0161 706 1851 first — do not book your own return, we arrange the collection.
Warranty12 months against manufacturing defects. Contact us and we will repair or replace.
Read before you buy — battery safety This is a high capacity lithium battery. Charge it on a hard non-flammable surface, never unattended and never overnight, and only with the charger supplied. Do not charge a pack that has been dropped, crushed, or is showing damage or swelling. If it gets hot or behaves oddly, stop, move it somewhere safe away from anything flammable, and contact us straight away.
